COOLING SYSTEM - F23

COOLING SYSTEM - F23

No.

01
P/N (SKU): 30006-060012840
Part Name: BOLT M6x12
Effective: 2021-02-26
Alternative parts: 30006-060012810
Specification: MILITARY GREEN
Price: 1,50 € : 1,50 €
02
P/N (SKU): 30301-060442
Part Name: WASHER
Effective: 2021-02-26
Remarks: φ10
Alternative parts: 30301-060412
Specification: 6
Price: 1,50 € : 1,50 €
03
P/N (SKU): 9010-180004
Part Name: RUBBER SLEEVE, RADIATOR
Effective: 2021-02-26
Alternative parts: null
Price: 6,00 € : 6,00 €
04
P/N (SKU): 9010-180010
Part Name: STEEL SLEEVE, RADIATIOR
Effective: 2021-02-26
Alternative parts: null
Price: 1,50 € : 1,50 €
05
P/N (SKU): 401B-180100
Part Name: RADIATOR ASSY
Effective: 2021-02-26
Remarks: Can be interchangeable if ordered with 401B-180003
Alternative parts: null
Price: 170,00 € : 170,00 €
05
P/N (SKU): 9010-180100-1000
Part Name: RADIATOR ASSY
Effective: 2021-02-26
Alternative parts: null
Specification: STAINLESS STEEL
Price: 171,00 € : 171,00 €
-+
06
P/N (SKU): 9010-180300
Part Name: WATER FILLING PORT CAP
Effective: 2021-02-26
Alternative parts: 8010-180024
Price: 7,50 € : 7,50 €
07
P/N (SKU): 30112-060012440
Part Name: null
Effective: 2021-02-26
Alternative parts: null
Specification: null
Price: 2,00 € : 2,00 €
08
P/N (SKU): 9010-180200-3000
Part Name: FAN&MOTOR
Effective: 2021-02-26
Alternative parts: null
Price: 109,00 € : 109,00 €
-+
08
P/N (SKU): 9010-180200-A000
Part Name: FAN&MOTOR
Effective: 2021-02-26
Remarks: HUALIN；isreplaced by 9010-180200-3000+9010-180201
Alternative parts: 9010-180200-3000+9010-180201
Price: 63,00 € : 63,00 €
09
P/N (SKU): 0010-135000
Part Name: THERMO SWITCH
Effective: 2021-02-26
Remarks: 80±4℃,Non-waterproofed
Alternative parts: null
Price: 16,00 € : 16,00 €
-+
10
P/N (SKU): 30601-112020
Part Name: STEEL WIRE ELASTIC RING HOOP
Effective: 2021-02-26
Alternative parts: 30601-112010
Price: 1,50 € : 1,50 €
11
P/N (SKU): 8060-180001
Part Name: RESERVOIR WATER PIPE
Effective: 2021-02-26
Alternative parts: null
Price: 7,50 € : 7,50 €
12
P/N (SKU): 30601-108520
Part Name: STEEL WIRE ELASTIC RING HOOP
Effective: 2021-02-26
Remarks: is replaced by 30601-108510
Alternative parts: 30601-109010
Price: 2,50 € : 2,50 €
13
P/N (SKU): 9010-180400-1000
Part Name: RESERVOIR TANK ASSY
Effective: 2021-02-26
Alternative parts: null
Price: 16,00 € : 16,00 €
-+
14
P/N (SKU): 9010-180005
Part Name: RESERVOIR OVERFLOW HOSE
Effective: 2021-02-26
Alternative parts: null
Price: 8,00 € : 8,00 €
-+
15
P/N (SKU): 0180-023500-0030
Part Name: CLAMP, WATER HOSE
Effective: 2021-02-26
Alternative parts: 9010-180007
Price: 3,00 € : 3,00 €
15
P/N (SKU): A000-180006
Part Name: CLAMP B30
Effective: 2021-02-26
Alternative parts: null
Specification: B30
Price: 3,00 € : 3,00 €
-+
15
P/N (SKU): 9010-180007
Part Name: WATER HOSE CLAMP
Effective: 2021-02-26
Alternative parts: null
Price: 3,00 € : 3,00 €
-+
16
P/N (SKU): 9010-180002
Part Name: RADIATOR WATER OUTLET HOSE
Effective: 2021-02-26
Alternative parts: null
Price: 22,00 € : 22,00 €
17
P/N (SKU): 401B-180003
Part Name: RADIATOR WATER INLET HOSE
Effective: 2021-02-26
Alternative parts: null
Price: 25,00 € : 25,00 €
-+
17
P/N (SKU): 9010-180003
Part Name: RADIATOR WATER INLET HOSE
Effective: 2021-02-26
Alternative parts: null
Price: 22,00 € : 22,00 €
-+
18
P/N (SKU): 5190-001003
Part Name: MAIN BRACKET RUBBER DAMPER
Effective: 2021-02-26
Alternative parts: null
Price: 1,50 € : 1,50 €
-+
19
P/N (SKU): 30006-060025840
Part Name: null
Effective: 2021-02-26
Alternative parts: null
Specification: null
Price: 1,50 € : 1,50 €
20
P/N (SKU): 8010-180023
Part Name: RESERVOIR CAP
Effective: 2021-02-26
Alternative parts: null
Price: 3,00 € : 3,00 €
-+
21
P/N (SKU): 8030-180302
Part Name: JOINT
Effective: 2021-02-26
Alternative parts: null
Price: 2,00 € : 2,00 €
22
P/N (SKU): 8010-180028
Part Name: RESERVOIR CONNECTING HOSE
Effective: 2021-02-26
Alternative parts: null
Price: 2,00 € : 2,00 €
-+
